LITZ HITECH LU-1200 - 5-Axis Vertical

Travel
X-Axis Travel mm 1100
Y-Axis Travel mm 1370 + 380
Z-Axis Travel mm 800
Distance From Spindle Nose To Table Surface mm 150 - 950
Worktable Dimension mm Ø 1150
Worktable Load kg 2000

Feed System
Rapid Feed ( X / Y / Z ) m / min 48 / 48 / 48
Cutting Feed( X / Y / Z ) m / min 0.001 - 20

Rotary Axis
A-Axis Rotation Angle degree ± 120 ﾟ
C-Axis Rotation Angle degree 360 ﾟ
A-Axis Max. Speed rpm 26
C-Axis Max. Speed rpm 50

Spindle System
Spindle Transmission Type Direct Drive (Standard) / Built-In (Op)
Spindle Speed ( max. ) rpm 8000
Spindle Power (Continuous / 30 Min.) kw ( HP ) 27 / 63 kw
Max. Torque Nm 400
Tool Handle Spec. # 50 BBT / CAT / DIN

Atc System
Magazine Capacity set 24 T (Standard)
Tool Change Method DRUM
Max. Tool Dis./ With Adjacent Tool mm Ø 125 / Ø 200
Max. Tool Length mm 400
Max. Tool Weight kg 15
Control System
Controller TNC - 640
Chips Conveyer Chanin-Type
Machine Occupancy (L X W X H) mm 5600 x 2980 x 4196
Machine Weight kg 32000
