5-axis Vertical Machining Centers

Vertical Turning Lathes

Featured Equipment

Built on Decades of Engineering Expertise

WSI Building
WSI Building

WSI is a global CNC machine builder and the innovation arm of a major manufacturing group, bringing over 30 years of experience in machine design, automation, and process engineering.

Through the INNOVA by WSI partnership, these machines are not simply imported—they are collaboratively engineered, configured, and supported specifically for North American production environments.

The result is a lineup of high-performance machining platforms that deliver the precision, rigidity, and long-term reliability modern shops demand.

Performance Without Compromise

  • Heavy-duty cast iron construction for maximum rigidity and thermal stability
  • High-speed, high-precision spindles up to 40,000 RPM
  • Industry-leading CNC controls (Fanuc) for reliability and familiarity
  • Compact machine footprints with full production capability
  • Built for automation, multi-axis machining, and continuous operation



WSI WVT-410
WSI WVT-410T

Engineered Platforms for Real Production

5-Axis Machining Centers (WVM Series)

Compact yet powerful platforms designed for complex geometries, tight tolerances, and high-speed contouring. These machines combine flexibility with production-level performance.

Compact 5-Axis Capability with Big-Machine Performance

The WVM Series combines precision, rigidity, and flexibility in a compact 5-axis machining platform. Designed for high-speed contouring, tight-tolerance work, and continuous operation, each model offers a different balance of spindle taper, tool capacity, and table size to fit your production needs.

Key Features

  • High-Speed, High-Precision Spindles — 15,000 to 40,000 rpm with BBT-30 / HSK-E40 to HSK-A63 interfaces.
  • Compact Footprint, Heavy Casting — Small overall size for shop efficiency, but built with large cast iron bases for thermal stability.
  • Fast Tool Changes — Tool-to-tool times as quick as 0.8 seconds and chip-to-chip in under 3 seconds.
  • Advanced Control Options — Fanuc 0i-MF or 31i-MF Plus controllers for 4+1 or full 5-axis simultaneous machining.
  • Exceptional Accuracy — ±0.005 mm positioning and ±0.006–0.02 mm repeatability (ISO 230-2).

Models

  • WVM-380U – Compact 5-axis machining center with 24–40 tool ATC and high-speed BBT-30/HSK-E40 spindle.
  • WVM-380UK – Mid-size platform with BBT-40/HSK-A63 spindle, 32–40 tool ATC, and larger work envelope.
  • WVM-410UT – Extended table travel and 40–60 tool ATC capacity, ideal for complex parts and multi-face machining.




WSI WVT-190
WSI WVT-190

Vertical Turning Lathes (WVT Series)

Space-efficient turning platforms built for precision and heavy cutting, offering exceptional accuracy and repeatability for small to mid-size components.

Compact, Rigid, and Built for Production Turning

The WVT Series delivers the power of a vertical turning lathe in a space-saving design, ideal for precision components and small to medium workpieces. With spindle options up to 4,500 rpm and heavy-duty cast iron construction, these machines handle high cutting loads while maintaining micron-level precision.


Key Features

  • Exceptional Accuracy — ±0.005 mm (±0.00020″) positioning with repeatability of ±0.006–0.02 mm (ISO 230-2).
  • High-Speed Spindles — 3,000–4,500 rpm, available in A2-6 or A2-8 configurations.
  • Compact Footprint — Fits where traditional horizontal lathes can’t, reducing floor space requirements.WVT190 with Gantry Bar Loader
  • Optional Live Tooling and CTS — Increases flexibility for complex turning and milling operations.
  • Proven Fanuc Control — Equipped with Fanuc 0i-TF for dependable operation and easy integration.

Models

  • WVT-190 – Compact VTL designed for precision turning, featuring a 40" table and 8" chuck.
  • WVT-190K – Adds increased torque and enhanced rigidity for heavy-duty cutting.
  • WVT-360 – Larger swing capacity for bigger parts, while maintaining the same compact platform and precision.





From multi-axis milling to production turning, WSI machines are designed to reduce setups, improve throughput, and maintain micron-level precision.


Manufactured for North America. Backed by INNOVA.

The INNOVA by WSI collaboration ensures every machine is aligned with real-world shop requirements—automation readiness, serviceability, and long-term support.

With North American distribution, application support, and service through Innova Machine Tool, customers gain more than a machine—they gain a long-term production partner.


    Built for High-Performance Applications
