INNOVA CS-VBM-4V Bed Type Vertical Boring & Milling Machines

CAPACITY
Table travel (Longitudinal) 1,200 mm (47-1/4 inch)
Table travel (Cross) 450 mm (17-11/16 inch)
Spindle head travel (Vertical) 550 mm (21-5/8 inch)
Spindle nose to table top 100 ~ 650 mm (3-15/16 ~ 25-5/8 inch)
Spindle center to column 450 mm (17-11/16 inch)

TABLE
Table working area 1,900 x 450 mm (74-13/16 x 17- 11/16 inch)
T slot (Wide x No. x Pach) 18 x 5 x 80 mm (0.709 x 5 x 3-1/8 inch)
Tabletop to floor 850 mm (33-1/2 inch)

SPINDLEHEAD
Spindle nose ISO R297 No.50
Spindle speed 35~1,250 (50Hz), 45~1,500 (60Hz)
No. of spindle speed 12 steps
Feeds (Vertical spindle) 0.05 ~ 0.2 (0.002 ~ 0.008 ipr) mm/rev.

FEED/RAPID
Rapid traverse (Longitudinal & cross)
50Hz
- 2,400 (94-7-16 ipm)
60Hz
- 2,880 (113-3/8 ipm)
Feed rates (Longitudinal & cross)
50Hz
- 23 ~ 730 (7/8 ~ 28-3/4 ipm)
60Hz
- 28 ~ 875 (1-1/8 ~ 34-7/16 ipm)
Change of feeds 12 steps

MOTORS
Vertical Spindle AC 7.5 kW (10HP)-4P
Feed of X, Y axis AC 1.5 kW (2HP)-4P
Feed of Z axis -
Lubrication AC 3.5 W
Cutting fluid AC 0.12 kW (1/16HP)-2P

MACHINE SIZE
Machine height 2,600 mm (102-3/8 inch)
Floor space (Longitudinal x cross) 3,800 x 2,210 mm (149-5/8 x 87 inch)
Net weight (Approx.) 5,200 kg (11,440 lbs)
Standard color Gray
